Calculates the absolute load impedance, reflection coefficient, VSWR, return loss and mismatch
loss of a load.
Enter the source characteristic impedance and the load impedance then press "Calculate" below.
INPUT DATA
Source Impedance:
Ohms
Load Impedance R:
Ohms
Load Impedance J:
Ohms
RESULTS
Absolute Load Impedance:
Ohms
Load Reflection Coefficient:
Load VSWR:
Load Return Loss:
dB
Load Mismatch Attenuation:
dB
This calculator uses JavaScript and will function in most modern browsers. For more information
see About our calculators.
The absolute value of the load impedance is calculated from the complex impedance (R + j).
Where R is the Real part of the impedance
and j is the Imaginary part of the impedance
The Load Reflection Coefficient ( Γ ) is calculated using the complex impedance of the load and
the characteristic impedance of the source.
Where Zo is the Source Impedance
The VSWR is then calculated using the Reflection Coefficient
The Reflection Coefficient is used again to calculate the Return Loss
The Reflection Coefficient is used yet again to calculate the Mismatch Loss
Various equations for Voltage Reflection Coefficient and VSWR are also available at:http://www.spectrum-soft.com/news/fall2009/vswr.shtm
Calculate VSWR from Forward and Reverse Power
Forward Power (W)
Reverse Power (W)
VSWR
Forward Power (dBm)
Reverse Power (dBm)
VSWR
